- Camera
- Image Sensor3K CMOS
- Signal SystemPAL/NTSC
- Resolution2960 (H) × 1665 (V)
- Frame Rate
TVI: 3K@20fps, 4 MP@25fps/30fps, 1080p@25fps/30fps
AHD: 5 MP@20fps, 4 MP@25fps/30fps
CVI: 4 MP@25fps/30fps
CVBS: PAL/NTSC
- Min. Illumination0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light
- Shutter TimePAL: 1/25 s to 1/50,000 s;NTSC: 1/30 s to 1/50,000 s
- Lens2.8 mm and 3.6 mm fixed focal lens
- Field Of View
2.8 mm, horizontal FOV: 102°, vertical FOV: 56°, diagonal FOV: 122°
3.6 mm, horizontal FOV: 80°, vertical FOV: 45°, diagonal FOV: 96°
- Lens MountM12
- Light AlarmSolid Light Alarm (White Light)
- Day & Night24/7 Color Imaging
- WDR (Wide Dynamic Range)Digital WDR
- Angle AdjustmentPan: 0° to 360°, Tilt: 0° to 90°, Rotation: 0° to 360°
- Image
- White LightAuto/Off
- Image ModeSTD/HIGH-SAT/HIGHLIGHT
- AGCYes
- Day/Night ModeColor
- White BalanceAuto/Outdoor/Global/Manual
- AE (Auto Exposure) ModeBLC;HLC;Global;HLS;DWDR
- Noise Reduction2D DNR
- LanguageEnglish
- FunctionDefective Pixel Correction;Sharpness;Mirror;Contrast;Brightness;Anti-Banding;Smart Light
- Interface
- Video OutputSwitchable TVI/AHD/CVI/CVBS
- Audio InBuilt-in mic
- General
- Operating Conditions-40°C to 60°C (-40°F to 140°F), Humidity: 90% or less (non-condensing)
- Power Supply
12 VDC ± 25%,
*You are recommended to use one power adapter to supply the power for one camera.
- ConsumptionMax. 2.5 W
- Protection LevelIP67
- MaterialPlastic
- White Light RangeUp to 20 m
- CommunicationHIKVISION-C
- Dimension161.1 mm × 70 mm × 70 mm (6.34″ × 2.76″ × 2.76″)
- WeightApprox. 238 g (0.52 lb.)
