- Network Parameters
- Ports8 × Gigabit RJ45 ports
- Port TypeRJ45 port, Full duplex, MDI/MDI-X adaptive
- StandardIEEE 802.3, IEEE 802.3u, IEEE 802.3x
- Forwarding ModeStore-and-forward switching
- MAC Address Table4 K
- Switching Capacity16 Gbps
- Packet Forwarding Rate11.904 Mpps
- Internal Cache1.5 Mbits
- General
- Dimensions (W × H × D)145 mm × 25.6 mm × 68.4 mm (5.7” × 1.0” × 2.7”)
- ShellMetal material, fan-free design
- Gross Weight0.38 kg (0.84 lb)
- Net Weight0.25 kg (0.60 lb)
- Operating Temperature0 ˚C to 40 ˚C (32 ˚F to 104 ˚F)
- Storage Temperature–40 ˚C to 85 ˚C (–40 ˚F to 185 ˚F)
- Storage Humidity5% to 95% (no condensation)
- Power Supply5 VDC,1 A
- Approval
- EMCFCC (ANSI C63.4, 47 CFR PART 15B); CE-EMC/RCM (EN 55032: 2015+A11:2020, EN IEC 61000-3-2: 2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4:2011+A1:2014, EN 55035:2017+A11:2020); IC (ICES-003: Issue 13)
- SafetyUL (UL 62368-1); CB (IEC 62368-1:2014); CE-LVD (EN 62368-1:2014+A11:2023)
- ChemistryCE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2012)
