| Standard: | TCP/IP |
| Sensor: | 1/3 ” Progressive Scan CMOS |
| Matrix size: | 4 Mpx |
| Resolution: | 2688 x 1520 – 4 Mpx , 1920 x 1080 – 1080p , 1280 x 720 – 720p |
| Lens: | 2.8 … 12 mm – Motozoom |
| View angle: |
|
| Range of IR illumination: | 40 m |
| RS-485 interface: | ![]() |
| Memory card slot: | Micro SD memory cards up to 256GB support (possible local recording) |
| Image compression method: | H.265+ / H.265 / H.264+ / H.264 / MJPEG |
| Alarm inputs / outputs: | 1 / 1 |
| Audio: |
|
| Network interface: | 10/100 Base-T (RJ-45) |
| Network protocols: | TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, IEEE 802.1x, QoS, IPv6, UDP, Bonjour, SSL / TLS, PPPoE |
| WEB Server: | Built-in, Web Viewer |
| Max. number of on-line users: | 6 |
| ONVIF: | 18.12 |
| Mobile phones support: | Port no.: 8000 or access by a cloud (P2P)
|
| Default admin user / password: | admin / – The administrator password should be set at the first start |
| Default IP address: | 192.168.1.64 |
| Web browser access ports: | 80 |
| PC client access ports: | Port no.: 8000 or access by a cloud (P2P) – iVMS-4200 application |
| Mobile client access ports: | 8000 |
| Port ONVIF: | 80 |
| RTSP URL: |
|
| Main stream frame rate: | 25 fps @ 4 Mpx |
| Main features: |
|
| Power supply: |
|
| Power consumption: |
|
| Housing: | Dome – Metal |
| Color: | White |
| “Index of Protection”: | IP67 |
| Vandal-proof: | IK10 |
| Operation temp: | -30 °C … 60 °C |
| Weight: | 1.23 kg |
| Dimensions: | Ø 153 x 112 mm |
| Supported languages: | Polish, English, Bulgarian, Croatian, Czech, Danish, Estonian, Finnish, French, Greek, Spanish, Dutch, Lithuanian, Latvian, German, Norwegian, Portuguese, Russian, Romanian, Serbian, Slovak, Slovenian, Swedish, Turkish, Ukrainian, Hungarian, Italian |
| Manufacturer / Brand: | Hikvision |
