Tiandy TC-C34QN 4MP Fixed IR Bullet Camera

₱2,975.00

KEY FEATURES

Metal+Plastic Housing
Up to 2560X1440@20fps
S+265/H.265/H.264
Min. illumination Color: 0.02Lux@F1.6
Smart IR, IR Range: 30m
Built-in Mic
Operating Conditions -30°~60°, 0~95% RH
POE, IP67

Add to wishlist

Categories: Tiandy, Tiandy Bullet, Tiandy IP Camera Tag: Tiandy TC-C34QN 4MP Fixed IR Bullet Camera

Description

Specifications
Model	TC-C34QN Spec:I3/E/Y/4mm/V5.0
Camera
Image Sensor	1/3″ CMOS
Min. Illumination	Color:0.02Lux@(F1,6,AGC ON),B/W:0Lux with IR
Shutter Time	1s to 1/100,000s
Day&Night	Dual IR-cut filter with auto switch
WDR	DWDR
S/N	>40dB
Angle Adjustment	0-360°;0-80;0-360°
Lens
Lens Type	Fixed
Focal Length	4mm
Lens Mount	M12
Aperture Range	F1,6,Fixed
Field of View	77.6°(H);44.1°(V);89.3 (D)
DORI Distance	Detect:80.0mObserve:31.8m Recognize:16.0m Identify:8.0m
Illuminator
IR LEDs	2
IR Distance	up to 30m
Wavelength	850nm
White LEDs	N/A
Whitelight Distance	N/A
Compression Standard
Video Compression	S+265/H.265/H.264B/H.264M/H.264H
Video Bit Rate	32k-6Mbps
Audio Compression	G.711A/G.711U
Audio Sampling Rate	8kHz
Max. Resolution	2560×1440@20fps
Main Stream	PAL:20fps(2560×1440,2304×1296,1920×1080,1280×720) NTSC:20fps(2560×1440,2304×1296,1920×1080,1280×720)
Sub Stream	PAL:20fps(704×576,704×288,352×288,640×360) NTSC: 20fps(704×480,704×240,352×240,640×360)
Third Stream	N/A
BLC	Yes
HLC	Yes
AGC	Yes
3D DNR	Yes
White Balance	Auto/Semi-auto/Manual/Sunny/Natural light/Warm light/Sodium lamp/Incandescent lamp/Locked white balance
ROI	N/A
Corridor Mode	N/A
EIS	N/A
OSD	1region;1616/32 32/4848/6464
Picture Overlay	N/A
Privacy Mask	4 regions
Defog	Yes
Network
ANR	N/A
Protocols	HTTP;TCP/IP;UDP;ICMP;DHCP;DNS;NTP;IPv4;Telnet;RTSP
System Compatibility	onvif Profile S/T,CGI;MIL STONE
Remote Connection	≤2
Client	Easy7 Smart Client
Mobile Client	EasyLive Plus
Web	IE10+;Firefox52+;Ed ge89+;Safari11+;Chrome57+
Interface
Communication Interface	1 RJ45 10M/ 100M self adaptive Ethernet port
Audio I/O	N/A
Alarm I/O	N/A
Built-In Mic	Yes
Built-In Speaker	N/A
Reset Button	N/A
On-board Storage	N/A
Additional Interfaces	N/A
General
Web Client Language	12 languagesEnglish, Arabic, Italian, Spanish, Japanese, Vietnamese, Thai, Turkish, Russian, Polish, Portuguese, French
Operating Temperature	-30°C-60C
Operating Humidity	0-95%
Storage Temperature	-30°С-60°С
Storage Humidity	0-95%(non-condensing)
Power Supply	N/A;POE 802.3af,MAX 6W
Protection	Surge protection 2000V;Lightning proof 6000V
Boundary Dimensions	164(L) 73(W) 73(H)mm
Package Dimensions	180(L)90(W)95(H)mm
GrossWeight	0.3Kg
NetWeight	0.22Kg
