DAHUA 2MP IR FIXED-FOCAL BULLET WIZSENSE NETWORK CAMERA (DH-HFW3241MN-AS-I2)

Name: DAHUA 2MP IR FIXED-FOCAL BULLET WIZSENSE NETWORK CAMERA (DH-HFW3241MN-AS-I2)
SKU: DAHUA 2MP IR FIXED-FOCAL BULLET WIZSENSE NETWORK CAMERA (DH-HFW3241MN-AS-I2)
Price: 6300.00 PHP
Availability: InStock

₱6,300.00

> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 2MP (1920 × 1080)@30 fps

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 80 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; Audio: In, out; supports max. 256 G Micro SD card

> 12V DC/PoE power supply, 12V power output, max. current 165mA

> IP67 protection

> SMD Plus

Add to wishlist

SKU: DAHUA 2MP IR FIXED-FOCAL BULLET WIZSENSE NETWORK CAMERA (DH-HFW3241MN-AS-I2) Categories: Dahua, Dahua Bullet, Dahua HD Analog and IP Cameras Tag: DAHUA 2MP IR FIXED-FOCAL BULLET WIZSENSE NETWORK CAMERA (DH-HFW3241MN-AS-I2)

Description

Camera

Image Sensor

1/2.8” 2Megapixel progressive CMOS

Max. Resolution

1920 (H) ×1080 (V)

ROM

128 MB

RAM

256 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.002 Lux@F1.6 (Color, 30IRE)

0.0002 Lux@F1.6 (B/W, 30IRE)

0 Lux (Illuminator on)

S/N Ratio

> 56 dB

Illumination Distance

80 m (262.5 ft)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (IR LED)

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

3.6 mm; 6 mm; 8 mm; 12 mm

Max. Aperture

3.6 mm, 6 mm, 8 mm: F1.6
12 mm: F2.0

Field of View

3.6 mm: Horizontal: 87°; vertical: 46°; diagonal: 104°
6 mm: Horizontal: 54°; vertical: 29°; diagonal: 63°
8 mm: Horizontal: 41°; vertical: 22°; diagonal: 47°
12 mm: Horizontal: 26°; vertical: 14°; diagonal: 30°

Iris Type

Fixed

Close Focus Distance

3.6 mm: 1.2 m (3.9 ft)
6 mm: 2.5 m (8.2 ft)
8 mm: 4 m (13.1 ft)
12 mm: 8.6 m (28.2 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6mm

55.2 m

(181.1 ft)

22.1 m

(72.5 ft)

11.0 m

(36.1 ft)

5.5 m

(18.0 ft)

6mm

82.8 m

(271.7 ft)

33.1 m

(108.6 ft)

16.6 m

(54.5 ft)

8.3 m

(27.2 ft)

8 mm

110.3 m (361.9 ft)

44.1 m

(144.7 ft)

22.1 m

(72.5 ft)

11.0 m

(36.1 ft)

12 mm

172.4 m (565.6 ft)

69.0 m

(226.4 ft)

34.5 m

(116.1 ft)

17.3 m

(56.8 ft)

Professional, Intelligent

Perimeter Protection

Tripwire; intrusion (Recognition of human and vehicle)

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG(only supported

by sub stream)

Smart Codec

Smart H.265+/ Smart H.264+

Video Frame Rate

Main stream (1920 × 1080@1–25/30 fps)
sub stream(704 × 576@1–25 fps/704 × 480@1–30 fps)
third stream(1280 × 720@1–25/30 fps)

Stream Capability

3 streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 3 Kbps–8192 Kbps
H.265: 3 Kbps–8192 Kbps

Day/Night

Auto(ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 1920 × 1080 resolution and lower.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G726

Alarm

Alarm Event

No SD card; SD card full; SD card error; less service time of SD card (smart card supports); network disconnection; IP conflict; illegal access; voltage detection; security exception; motion detection; video tampering; scene changing; input abnormal; intensity change; tripwire; intrusion; SMD

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Protocol

IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; SNMP

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Interoperability

ONVIF(Profile S/Profile G/Profile T);CGI;P2P;Milestone;

Genetec

Scene Self-adaptation (SSA)

Yes

User/Host

20 (Total bandwidth: 64 M)

Storage

FTP; SFTP;Micro SD Card (support max. 256 G); NAS

Browser

IE: IE8, IE9, IE11

Chrome

Firefox

Management Software

Smart PSS, DSS, DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

Audio Input

1 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

2 channels in: 5mA 3V–5V DC

Alarm Output

2 channels out: 300mA 12V DC

Power

Power Supply

12V DC/PoE (802.3af)

Power Consumption

<11W

Environment

Operating Conditions

-40°C to +60°C (-40°F to +140°F)/less than 95%

Storage Conditions

-40°C to +60°C (-40°F to +140°F)

Protection Grade

IP67

Structure

Casing

Metal + Plastic

Dimensions

194.4 mm × 96.6 mm × 89.5 mm

(7.7″ × 3.8″ × 3.5″) (L × W × H)

Net Weight

755g (1.7 lb)

Gross Weight

875g (1.9 lb)
