Camera
Image Sensor
1/2.8” 2Megapixel progressive scan STARVIS™ CMOS
Effective Pixels
1920(H) x 1080(V)
RAM/ROM
512MB/128MB
Scanning System
Progressive
Electronic Shutter Speed
Auto/Manual, 1/3~1/100000s
Minimum Illumination
0.002Lux/F1.6 ( Color,1/3s,30IRE)
0.012Lux/F1.6 ( Color,1/30s,30IRE)
0Lux/F1.6 (IR on)
IR Distance
Distance up to 80m (262ft)
IR On/Off Control
Auto/ Manual
IR LEDs
4
Lens
Lens Type
Fixed
Mount Type
Board-in
Focal Length
2.8mm,3.6mm,6mm,8mm,12mm
Max. Aperture
F1.6(2.8mm~8mm),F2.0(12mm)
Angle of View
H: 106°, V:57°/H: 87°, V:46°/H: 53°, V:30°/
H: 41°, V:23°/H: 26°, V:14°
Optical Zoom
N/A
Aperture Type
Fixed
Close Focus Distance
0.6m(1.97ft)/1.2m(3.94ft)/2.5m(8.20ft)/
4m(13.12ft)/8.6m(28.22ft)
DORI Distance
Lens
Detect
Observe
Recognize
Identify
2.8mm
39m(128ft)
15m(49ft)
8m(26ft)
4m(13ft)
3.6mm
55m(180ft)
22m(72ft)
11m(36ft)
6m(20ft)
6mm
83m(272ft)
33m(108ft)
17m(56ft)
8m(26ft)
8mm
110m(361ft)
44m(144ft)
22m(72ft)
11m(36ft)
12mm
172m(564ft)
69m(226ft)
35m(115ft)
17m(56ft)
Pan/Tilt/Rotation
Pan/Tilt/Rotation Range
Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚
Artificial Intelligence
Face Capture
Support face image capture
Face Attributes
Support 6 kinds of face attributes extraction: Age, Gender,Expression(Jolly/Surprise/Normal/Rage/Sad/Disgusted/Confused/Frightened), Glasses,Mouth Mask, Moustache & Beard
Perimeter Protection
Tripwire, Intrusion(Human & Vehicle classification)
People Counting
Line crossing people counting, Region people counting
General Intelligence
Event Trigger
Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly
General Intelligence
Object Abandoned/Missing
Frame Rate
Main Stream: 1080P(1~25/30fps)
Sub Stream: D1(1~25/30fps)
Third Stream: 1080P(1~6fps)
Bit Rate Control
CBR/VBR
Bit Rate
H.264: 32~ 8192Kbps
H.265: 19~ 7424Kbps
Day/Night
Auto(ICR) / Color / B/W
BLC Mode
BLC / HLC / WDR(120dB)
White Balance
Auto/Natural/Street Lamp/Outdoor/Manual
Gain Control
Auto/Manual
Noise Reduction
3D DNR
Motion Detetion
Off / On (4 Zone, Rectangle)
Region of Interest
Off / On (4 Zone)
Electronic Image Stabilization (EIS)
N/A
Smart IR
Support
Defog
Support
Digital Zoom
N/A
Flip
0°/90°/180°/270°
Mirror
Off / On
Privacy Masking
Off / On (4 Area, Rectangle)
Audio
Compression
N/A
Network
Ethernet
RJ-45 (10/100Base-T)
Protocol
HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP;SMTP;
FTP; DHCP; DNS; DDNS; PPPoE; IPv4/v6; SNMP;QoS;
UPnP;NTP
Interoperability
ONVIF(Profile S/Profile G), CGI,Milstone,Genetec,P2P
Streaming Method
Unicast / Multicast
Max. User Access
20 Users
Edge Storage
NAS
FTP
Mirco SD card 256GB
Web Viewer
IE(versions newer than IE8), Chrome,
Firefox, Safari(versions newer than Safari 12)
Management Software
Smart PSS, DSS, P2P
Smart Phone
iOS, Android
